Bimorph piezoelectric ceramics, ceramic, power generation, piezoelectric power generation 60X30

(No reviews yet) Write a Review
SKU:
PEPIE46
Weight:
0.06 KGS
Shipping:
Calculated at Checkout
$29.70

Description

Material parameters

Bimorph piezoelectric generator, parallel type, use method:

1 connection method: the positive and negative sides of the ceramic wire together with lead out an electrode, copper lead out an electrode;

2 cantilever support, the maximum deformation of the free end 7mm;

3 simple support, the maximum displacement of the middle position 3mm;

Voltage output value: 0< U< 15V; current output value: 0< I< 8ma.
bimorph-piezoelectric-ceramics-ceramic-power-generation-piezoelectric-power-generation-60x30.jpg-640x640.jpg
