SN74LS08N, Quad 2-Input AND Logic Gate IC

(No reviews yet) Write a Review
SKU:
PERTY16
Weight:
0.01 KGS
Shipping:
Calculated at Checkout
$0.39

Description

Specification

AttributeValue
Logic Function AND
Mounting Type Through Hole
Number of Elements 4
Number of Inputs per Gate 2
Schmitt Trigger Input No
Package Type PDIP
Pin Count 14
Logic Family LS
Maximum Operating Supply Voltage 5.25 V
Maximum High Level Output Current -0.4mA
Maximum Propagation Delay Time @ Maximum CL 20 ns @ 5 V
Minimum Operating Supply Voltage 4.75 V
Maximum Low Level Output Current 8mA
Propagation Delay Test Condition 15pF
Dimensions 19.3 x 6.35 x 4.57mm
Height 4.57mm
Maximum Operating Temperature +70 °C
Width 6.35mm
Length 19.3mm
Minimum Operating Temperature 0 °C

Technical data sheets

Package Includes
1pc x SN74LS08N, Quad 2-Input AND Logic Gate IC
